| Frequency Range |
25Hz-400Hz (-3dB) In Room Response
|
| Power Handling |
150-600* Watts recommended amplifier power.
* The use of a power amplifier with high pass filter and soft limiter function is strongly recommended
on Passive sub woofers(If use Passive Models).
|
| Sensitivity |
90dB for 2.83 volts at 1 meter
|
| Impedance |
4Ω |
| Enclosure Type |
Bass reflex, front vented |
| Driver |
Low Frequency Driver-Single10” paper cone driver with 65 mm (2.56 in) long throw voice coil
developed for high level, low frequency reinforcement
|
| Input Terminal |
Push To Hold type |
| Dimensions |
426mm high x 426mm wide x 609mm deep
|
